Environmental Radiation Monitoring System
SERM-3000
Overview
- Fixed-type environmental radiation monitoring system for real-time radiation surveillance
- The fixed environmental radiation monitor can display GPS coordinates and radiation dose rates on a map in real time through wireless communication from remote locations. It also enables real-time radiation dose measurement and artificial radionuclide analysis.
Features
- Equipped with NaI(Tl) Scintillator (3" × 3")
- Measurement range: 0.01μSv/h ~ 50.0μSv/h
- Operating temperature: -30°C ~ 60°C
- Operating humidity: Below 90%RH
- Energy range: 30keV ~ 3MeV
- 24-hour continuous real-time fixed environmental radiation dose rate monitoring system
- GPS coordinates and measurement data are recorded by time and transmitted to the central monitoring system
- Real-time discrimination between natural and artificial radiation dose rates
- Real-time artificial radionuclide identification
- Auto-Gain system with temperature compensation algorithm
- Built-in 1024-channel MCA (Multi-Channel Analyzer)
